GOLD NOTE DS-10 EVO USB DAC / STREAMER /PREAMPLIFIER , a DIAMOND DAC !!
 |
| GOLD NOTE DS-10 EVO USB DAC - STREAMER - PREAMPLIFIER . a DIAMOND DAC |
GOLDNOTE DS-10 & external Inductive Regulated POWER SUPPLY
TIDAL - ROON - SPOTIFY - AIRPLAY - QOBUZ - MQA - DEEZER - VTUNER -5.0 Bluetooth
 |
GOLDNOTE DS-10 *AWARD
WINNER 2022 * HI-FI Plus |
** THE
MOST COMPLETE D/A CONVERTER , STREAMER , & Α
COMPLETE DIGITAL AUDIO SOURCE
DIGITAL AUDIO DAC & FULL FUNCTION STREAMER , α DIAMOND DAC !!
PREAMPLIFIER
& HEADPHONE AMPLIFIER . Oδηγει απ`ευθειας Ενεργα Ηχεια .
More time for music, less time to make it work.
Δεν εχει ανταγωνισμο με αλλα DAC Πολλαπλασιας αξιας !!!
Τιμη Προσφορας : DS-10 2.670 e
Δεχεται το εξωτερικο Τροφοδοτικο PSU-10 + 1.050 e
* Inductive Power Supply με σημαντικη βελτιωση στην ποιοτητα Ηχου.
info : WWW.NEXUSACOUSTICS.COM 210-9850286 xaitas1@gmail.com
A COMPLETE DIGITAL AUDIO SOURCE
DS-10 is designed to cover the needs of the contemporary audiophile completing any audio system offering almost all kind of Internet and Digital connectivity with the purity of the premium Gold Note High-End audio sound performance in a convenient elegant shape. DS-10 is an innovative D/A Converter inspired from the acclaimed top model DS-1000 merging the extended features of IS-1000 All-In-One unit adding even something more. Most importantly, it’s quick to install and easy to use every day making DS-10 a complete unit to be integrated into any High-End audio system.
DIGITAL AUDIO DAC & FULL FUNCTION STREAMER
DS-10 is a new generation D/A Converter & UPnP, DLNA Streamer created to revolution any audio system being able to browse Web Streaming Players and Digital Sources.
DS-10 can be matched with traditional CD players, TV or Media Servers as well as it is compatible with almost all internet services including Roon, Tidal, Qobuz, Airplay, Spotify, Deezer,
V-Tuner, from which it can play DSD, PCM & MQA formats all to enjoy real
"High-End Audio" as a new refreshing experience, hassle and cable
free. You can connect your devices via Wifi/LAN but also via the last
generation high definition digital Bluetooth 5.0 to guarantee best performance
and easy connectivity with any device matched.
Thanks to its versatile design DS-10 converts D/A audio via S/PDIF coaxial, TOS-optical, AES Asynchronous PCM 24bit/192 kHz inputs, one USB-B Host asynchronous for native and DoP DSD 64/128 and PCM up to 32bit/384kHz. It also plays directly from HardDisk and USB sticks
(FAT32/NTFS) via USB-A directly.
DS-10 is a true High-End Audio DAC capable
of audiophile sound from digital files featuring Streamer & Network Player
functions to help enjoying your favorite music always with the greatest audio
quality, fully controlled via App, remote and front knob to make it works super
easily.
PREAMPLIFIER & HEADPHONE AMPLIFIER
DS-10 features an On/Off switchable High-End
audio analogue preamp stage synchronized with all the remote control including
a computer App which let the unit always play via the analogue stage, even with
web players, guaranteeing the best performance ever.
DS-10 features a professional 6.3mm headphone
output with a proprietary design which allows selecting the sensitivity to
drive almost any kind of headphone of the market. It will always be
playing pure audio without compromise. No digital, no poor quality volume
controls.
DURABLE DESIGN 100% MADE IN ITALY
DS-10 features a great mechanical structure
made of solid machined aluminium which guarantees low frequency resonance and
magnetic inertial field. The compact and iconic air vent design derives straight
from the acclaimed PH-10 phono stage.
GOLD NOTE MODULAR DESIGN
Thanks to its innovative and unique modular
design DS-10 will optionally be able to perform a very special external power
supply to effectively enhance the native performance of the unit.
More time for music, less time to make it work
NEW TOTAL CONTROL OVER YOUR AUDIO SYSTEM
The nice looking 2.8” TFT monitor shows the unit information and the App allows to
fully control the unit’s functions. While the unit is also equipped with a
handset remote control our proprietary SKC technology - Single Knob Control -
makes it easy and quick to control DS-10 using a single joggle.
IOS & ANDROID APP
DS-10 DAC features easy set up Apple iOS and Android proprietary software for full
control via iPhones and iPads as well as smart phones and tablets. The App
makes it easy to fully control DS-10 synchronising the unit to all functions
and lets even the Web Player play analogue volume when the preamp stage is
activated.
TECHNICAL SPECIFICATIONS
MAIN FEATURES
D/A Converter native PCM up to 32bit/384kHz & DSD 64/128 native, via
DoP and PCM Streamer & Network Player PCM and DSD64
Frequency response: 20Hz-20kHz +/-0.1dB
THD – Total Harmonic Distortion: 0.001% max
Signal to Noise ratio: -125dB
Dynamic range: 120dB
Output impedance: 50ohm
Preamp Stage Volume Control: enabled/disabled by remote
POWER
Multiple Transformer proprietary power supply.
Power consumption: 30W - 230 V
DIGITAL INPUTS
1Ethernet LAN & Wi-Fi (DSD64 via PCM) Resolution: PCM up to 24bit/192kHz
1x RCA S/PDIF coaxial PCM asynchronous up to 24bit/192kHz
2x TOS-optical PCM asynchronous up to 24bit/192kHz
1x AES/EBU balanced PCM asynchronous up to 24bit/192kHz
1 x USB-B asynchronous native and DoP DSD64/128 and PCM up to 32bit/384kHz
1x USB-A port to feed USB flash memories and HDD, FAT32/NTFS formatted playing DSD64 and PCM up to 24bit/192kHz
1x RCA S/PDIF coaxial PCM asynchronous up to 24bit/192kHz
2x TOS-optical PCM asynchronous up to 24bit/192kHz
1x AES/EBU balanced PCM asynchronous up to 24bit/192kHz
1 x USB-B asynchronous native and DoP DSD64/128 and PCM up to 32bit/384kHz
1x USB-A port to feed USB flash memories and HDD, FAT32/NTFS formatted playing DSD64 and PCM up to 24bit/192kHz
AUDIO OUTPUTS
Line output level (fixed): stereo RCA @ 1Volt and balanced XLR @ 4Volt
CONNECTIVITY
LAN/WLAN
WiFi: 802.11b/g via RJ45 10/100Mbps socket and Antenna playing native and DoP
DSD64/128 and PCM up to 24bit/192kHz
Blueooth 5.0
Infrared remote: RC5 proprietary code
Blueooth 5.0
Infrared remote: RC5 proprietary code
SUPPORTED AUDIO FORMATS
AIFF (.aif, .aiff, .aifc) ALAC WAV (.wav) packed/unpacked FLAC WmA Windows media Audio 9
WAX Windows media audio metafiles ASX Advanced Stream Redirector (.asx) MP3 DSD (.dsf & .dff via USB-B)
WAX Windows media audio metafiles ASX Advanced Stream Redirector (.asx) MP3 DSD (.dsf & .dff via USB-B)
SUPPORTED MEDIA SERVERS
Minim Bubble UPnP all UPnP certified media servers
DIMENSIONS & WEIGHT
220mm W | 80mm H | 260mm D 4 Kg
finishes CASE : Brushed Aluminium | Black, Silver or Gold
 |
Εξαιρετικη Ποιοτητα κατασκευης.  |
